Transformers from the composition and production process, is a combination of physical labor and technical live. While the assembly process, it is labor-intensive industries. From the winding, insulation, assembly and a series of links, are labor-intensive industries, can not achieve a unified mechanized production, need to hand to complete. Xiaobian to the following to understand the transformer production process with it

First of all, its basic composition: Transformer body: Ming steel, winding, which is the main transformer.
Followed by the shell, placed body, protector body, with insulating oil.
Once again, oil pillow, transformer oil surface due to temperature rise, the excess oil into the oil pillow, oil storage effect. Insulation sleeve, lead wire plus protection.
Finally, casters, installed to move with. These five aspects of interaction, are indispensable.

Of course, before the start of the transformer production, the need to design, in the confirmation of the design, we need to pay attention to both around the sister and insulation. First confirm whether the drawings are consistent with the production of products, to confirm its capacity and then look at the wire gauge, find the line after the confirmation of the number of turns. Second, to confirm what kind of wiring (star and triangle), high-pressure drawings to see their tap, the number of good head turns, low voltage is optimistic about what kind of winding, the length of the first, transposition position, winding diameter , To the size and so on. Second, according to the length of the paper tube calculated by the length of paperboard, followed by drawing from the drawing number to find the end of the insulation length of the drawings, including the oil block and corrugated oil pipe thickness, in turn find the end ring and the upper and lower iron yoke insulation.
